Safe Use Instructions – Emerson FloBoss 104 Flow Manager
Part D301733X012
February 2018
6 www.Emerson.com/RemoteAutomation
A
FloBoss 104 nameplate
B
DVS Sensor label
Figure 8. FloBoss 104 Dimensions
A
¾ - 14 NPT Field Wiring entries
Figure 9. FloBoss 104 Mounting Styles
B
A
B
A
