Emerson FPCSK - 4.4 Affinity Recommended Programming

22

Parameter
Menu 0
Equivalent
Description
Setting Units
Fan
Pump
1.06 0.02
Maximum set
speed
60.0 60.0 Hz
1.07 0.01
Minimum set
speed
15.0 6.0 Hz
2.11 0.03
Acceleration rate
1
100.0 16.6 s/100 Hz
2.21 0.04
Deceleration rate
1
100.0 16.6 s/100 Hz
5.07 0.46
Motor rated
current
From Motor A
5.08 0.45
Motor load
rpm/rated speed
From Motor RPM
5.09 0.44
Motor rated
voltage
From Motor V
5.13 0.09
Dynamic V/ F flux
optimise select
OFF OFF -
6.09 0.33
Catch a spinning
motor
1 1 -
7.19 -
T9 analog output 1
source
5.01 5.01 menu.param
7.33 -
T9 analog output 1
control
Adv Adv -
8.21 -
T24 digital I/O
source/destination
10.02 10.02 menu.param
11.44 0.49 Security status L2 L2 -
Note: If the analog speed reference into VFD terminal 7 is 0–10 Vdc instead of
the default 4–20 mA, parameter 7.11 (menu 0 parameter 0.19) must be
changed to VOLt (4).
