Emerson MICRO MOTION 2700 - Codes and Abbreviations Used in Display Menus

Displaycodesandabbreviations
TableA-1Displaycodesforprocessvariablescontinued
CodeDenitionCommentorreference
PWRINInputvoltage
Referstopowerinputtothecore
processor
RDENSDensityatreferencetemperatureConcentrationmeasurement
applicationonly
RPO_ARightpickoffamplitude
SGUSpecicgravityunits
STDVStandardvolumeowrateConcentrationmeasurement
applicationonly
STDVIStandardvolumeinventoryConcentrationmeasurement
applicationonly
TCDENS
Temperature-correcteddensityPetroleummeasurementapplication
only
TCORI
Temperature-correctedinventoryPetroleummeasurementapplication
only
TCORR
Temperature-correctedtotalPetroleummeasurementapplication
only
TCVOL
Temperature-correctedvolumePetroleummeasurementapplication
only
TUBEF
Rawtubefrequency
WTAVEWeightedaverage
A.2Codesandabbreviationsusedindisplaymenus
TableA-2listsanddenesthecodesandabbreviationsusedinthedisplaymenus.
TableA-2Codesandabbreviationsusedindisplaymenus
Codeor
abbreviationDenitionCommentorreference
ACKALARM
Acknowledgealarm
ACKALL
Acknowledgeallalarms
ACT
Action
ADDRAddress
AO1SRC
Fixedtotheprocessvariableassignedtotheprimaryoutput
AO1Analogoutput1(primarymAoutput)
AO2Analogoutput2(secondarymAoutput_
AUTOSCRLLAutoScroll
BKLT
BLIGHT
Backlight
CALCalibrate
CHAChannelA
CHBChannelB
CHCChannelC
34
MicroMotionModel2700TransmitterswithIntrinsicallySafeOutputs
