Integratethemeterwiththecontrolsystem
2.2CongurethemAoutputs
Display
OFF-LINEMAINT→OFF-LINECONFG→IO→CHA
OFF-LINEMAINT→OFF-LINECONFG→IO→CHC
ProLinkII
ProLink→Conguration→AnalogOutput
Communicator
5,3,1
DetailedSetup→CongOutputs→AnalogOutput1
5,3,2
DetailedSetup→CongOutputs→AnalogOutput2
ThemAoutputisusedtoreportaprocessvariable.ThemAoutputparameterscontrolhowthe
processvariableisreported.YourtransmitterhastwomAoutputs:ChannelAandChannelC.
ThemAoutputparametersinclude:
▪mAOutputProcessVariable
▪LowerRangeValue(LRV)andUpperRangeValue(URV)
▪AOCutoff
▪AddedDamping
▪AOFaultActionandAOFaultValue
Prerequisites
IfyouplantocongureanmAoutputtoreportvolumeow,ensurethatyouhavesetVolumeFlow
Typeasdesired:LiquidorGasStandardVolume.
IfyouplantocongureanmAoutputtoreportaconcentrationmeasurementprocessvariable,
ensurethattheconcentrationmeasurementapplicationisconguredsothatthedesiredvariableis
available.
Postrequisites
Important
WheneveryouchangeanmAoutputparameter,verifyallothermAoutputparametersbefore
returningtheowmetertoservice.Insomesituations,thetransmitterautomaticallyloadsasetof
storedvalues,andthesevaluesmaynotbeappropriateforyourapplication.
2.2.1ConguremAOutputProcessVariable
Display
OFF-LINEMAINT→OFF-LINECONFG→IO→CHA→AO1SRC
OFF-LINEMAINT→OFF-LINECONFG→IO→CHC→AO2SRC
ProLinkII
ProLink→Conguration→AnalogOutput→PVIs
ProLink→Conguration→AnalogOutput→SVIs
Communicator
5,3,1,1
DetailedSetup→CongOutputs→AnalogOutput1→PVIs
5,3,2,1
DetailedSetup→CongOutputs→AnalogOutput2→SVIs
mAOutputProcessVariablecontrolsthevariablethatisreportedoverthemAoutput.
4
MicroMotionModel2700TransmitterswithIntrinsicallySafeOutputs
