Acceptable lifting pointsFigure 2-1:
Center of gravity for large metersFigure 2-2:
A
A. Typical center of gravity
Note
Complete and detailed dimensional drawings, including the location of the center of gravity, can be
found through the product drawings link in our online store (www.emerson.com).
Mounting
Installation Manual 9
