Emerson Micro Motion ELITE User Manual

2 Micro Motion
®
ELITE
®
Sensor Instruction Manual
Before You Begin
continued
Components of the CMF010 sensor
With junction box
Flow direction
arrow
Purge connections or
rupture disks
(optional)
Calibration tag
Sensor
housing
Junction box
Junction box side of
sensor
Reverse side of
sensor
Process fitting
Thru-holes for
alternative
mounting
Approvals tag
With core processor
Flow direction
arrow
Purge connections or
rupture disks
(optional)
Calibration tag
Sensor
housing
Core processor
housing
Core processor side
of sensor
Reverse side of
sensor
Process fitting
Thru-holes for
alternative
mounting
Approvals tag
CMF010: Side view of extended
mount junction box
CMF010: Side view of extended
mount core processor
Junction box
Sensor
Extension
Core
processor
Sensor
Extension
