Emerson Micro Motion ELITE User Manual

Micro Motion
®
ELITE
®
Sensor Instruction Manual 3
Before You Begin
continued
Wiring Startup TroubleshootingBefore You Begin Location Orientation Mounting
Components of the CMF025, CMF050, and CMF100 sensor
With junction box
With core processor
Flow direction
arrow
Process fitting
Purge
connections
(optional)
Approvals tag
Sensor
housing
Junction box
Calibration tag
CMF050: Side view of extended
mount junction box
CMF050: Side view of extended
mount core processor
Junction box
Sensor
Extension
Core
processor
Extension
Sensor
Approvals
tag
Flow direction arrow
Core processor housing
Serial
number tag
Optional purge connections
or rupture disks
Process
connection
Sensor
housing
