Emerson MultiFlex Series User Manual

Setting the Terminating Resistance Jumpers The I/O Network • 13
nate a MultiFlex, these jumpers must be set to
the IN (toward the center of the board) position.
Figure 3-6 shows the termination jumper set-
tings for all MultiFlex boards.
Figure 3-6 - I/O Network Termination Jumper Settings
S4 S3 S2 S1
2345678
1
ON
2345678
1
ON
2345678
1
ON
2345678
1
ON
TERMINATION JUMPERS
NO TERMINATION - IN (toward center)
TERMINATION - OUT (toward left edge)
