5
emersonfans.com
Please contact 1-800-654-3545 for further assistance
U.L. Model No.: 52-ANT
IMPORTANT
Your ceiling fan is designed to be installed either in the standard manner, or in the
close-to-the-ceiling manner. Using the standard method, the hanger ball/downrod assembly will suspend
the fan several inches below the ceiling cover. Using the close-to-the-ceiling method, the ceiling cover
i
nstalls directly on the fan motor housing, thus mounting the fan 3-1/2 inches closer to the ceiling than the
standard method. In no case should the fan blades be lower than seven feet above the floor. Depending
on your desired mounting method, proceed to “INSTALLING HANGER BALL/DOWNROD ASSEMBLY” for
standard mounting, or to “INSTALLING CEILING COVER ON FAN MOTOR HOUSING” for close-to-the-
ceiling mounting.
3. Removal of the Hanger Bracket
REMOVE AND RETAIN
TWO SCREWS AND LOCKWASHERS
LOOSEN THE TWO
SCREWS IN THE
KEYHOLE SLOTS
CEILING
COVER
HANGER
BRACKET
ROTATE CEILING COVER COUNTER-CLOCKWISE TO REMOVE
THE HANGER BRACKET
3.1
Loosen the Two Screws in the Keyholes Slots of the
Ceiling Cover.
Remove and retain the other Two Screws and
Lockwashers (Figure 1).
Turn the Ceiling Cover and remove the Hanger
Bracket.
Figure 1
To Next Page
