6
U.L. Model No.: 52-ANT
4. Installing the Hanger Ball/Downrod Assembly
(For Standard Mounting)
4.2
Separate, untwist and unkink the Three Motor Wires.
Route the Motor Wires through the Hanger Ball /
Downrod Assembly (Figure 3).
HANGER BALL/
4.5" DOWNROD
ASSEMBLY
THREE 80" MOTOR
WIRES
Figure 3
THREE 80" MOTOR
WIRES
CEILING
COVER
4.1
P
ass the 80" Motor Wires through the opening in the
Ceiling Cover.
Be sure the Cover is oriented correctly (Figure 2).
Figure 2
To Next Page
