Product Data Sheet
00813-0100-4530, Rev DA
December 2010
Rosemount 5300 Series
6
4V Dynamic Vapor Compensation
Single Rigid Probe for 3-4 in. pipes
(13)
Flange / 1.5 in. Thread
Min: 2 ft 5 in. (0.76 m). Max:
13 ft (4 m)
Probe Length Units
Standard Standard
E English (feet, in.) ★
M Metric (meters, centimeters) ★
Total Probe Length
(14)
(feet/m)
Standard Standard
xxx 0-164 ft or 0-50 m ★
Total Probe Length
(14)
(in./cm)
Standard Standard
xx 0-11 in. or 0-99 cm ★
Process Connection - Size / Type (consult the factory for other process connections)
ASME / ANSI Flanges
(15) (16)
Standard Standard
AA 2 in., 150 lb ★
AB 2 in., 300 lb ★
AC 2 in., 600 lb. HTHP / HP units ★
AD 2 in., 900 lb. HTHP / HP units ★
BA 3 in., 150 lb ★
BB 3 in., 300 lb ★
BC 3 in., 600 lb. HTHP / HP units ★
BD 3 in., 900 lb. HTHP / HP units ★
CA 4 in., 150 lb ★
CB 4 in., 300 lb ★
CC 4 in., 600 lb. HTHP / HP units ★
CD 4 in., 900 lb. HTHP / HP units ★
Expanded
AE 2 in., 1500 lb. HTHP / HP units
AI 2 in., 600 lb, RTJ (Ring Type Joint). HTHP / HP units
AJ 2 in., 900 lb, RTJ (Ring Type Joint). HTHP / HP units
AK 2 in., 1500 lb, RTJ (Ring Type Joint). HTHP / HP units
BE 3 in., 1500 lb. HTHP / HP units
BI 3 in., 600 lb, RTJ (Ring Type Joint). HTHP / HP units
BJ 3 in., 900 lb, RTJ (Ring Type Joint). HTHP / HP units
BK 3 in., 1500 lb, RTJ (Ring Type Joint). HTHP / HP units
CE 4 in., 1500 lb. HTHP / HP units
CI 4 in., 600 lb, RTJ (Ring Type Joint). HTHP / HP units
CJ 4 in., 900 lb, RTJ (Ring Type Joint). HTHP / HP units
CK 4 in., 1500 lb, RTJ (Ring Type Joint). HTHP / HP units
DA 6 in., 150 lb
EN (DIN) Flanges
(17) (18)
Standard
HB DN50, PN40 ★
HC DN50, PN63. HTHP / HP units ★
HD DN50, PN100. HTHP / HP units ★
IA DN80, PN16 ★
TABLE 1. 5301 and 5302 Level and/or Interface in Liquids Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
The Expanded offering is subject to additional delivery lead time.
