Field Communicator Menu Trees and Fast Keys
July 2018
Reference Manual
00809-0200-4728, Rev SA
Field Communicator Menu Trees and Fast Keys
96
Software Revision 1, 8, 2, 4 1, 8, 2, 4
Tag 2, 2, 7, 1, 1 2, 2, 7, 1, 1
Long Tag N/A 2, 2, 7, 1, 2
Terminal Temperature 2, 2, 7, 1 2, 2, 8, 1
URV (Upper Range Value) 2, 2, 5, 5, 2 2, 2, 5, 5, 2
USL (Upper Sensor Limit) 2, 2, 1, 7, 2 2, 2, 1, 8, 2
Variable Mapping 2, 2, 8, 5 2, 2, 8, 5
2-wire Offset Sensor 1 2, 2, 1, 9 2, 2, 1, 10
2-wire Offset Sensor 2 2, 2, 2, 9 2, 2, 2, 10
Table B-2. Device Revision 7 Field Communicator Traditional Fast Key Sequences
Function Fast Keys Function Fast Key
Active Calibrator 1, 2, 2, 1, 3 Num Req Preams 1, 3, 3, 3, 2
Alarm/Saturation 1, 3, 3, 2 Open Sensor Hold off 1, 3, 5, 3
AO Alarm Type 1, 3, 3, 2, 1 Percent Range 1, 1, 5
Burst Mode 1, 3, 3, 3, 3 Poll Address 1, 3, 3, 3, 1
Burst Option 1, 3, 3, 3, 4 Process Temperature 1, 1
Calibration 1, 2, 2 Process Variables 1, 1
Callendar-Van Dusen 1, 3, 2, 1 PV Damping 1, 3, 3, 1, 3
Configuration 1, 3 PV Unit 1, 3, 3, 1, 4
D/A Trim 1, 2, 2, 2 Range Values 1, 3, 3, 1
Damping Values 1, 1, 10 Review 1, 4
Date 1, 3, 4, 2 Scaled D/A Trim 1, 2, 2, 3
Descriptor 1, 3, 4, 3 Sensor Connection 1, 3, 2, 1, 1
Device Info 1, 3, 4 Sensor 1 Setup 1, 3, 2, 1, 2
Device Output Configuration 1, 3, 3 Sensor Serial Number 1, 3, 2, 1, 4
Diagnostics and Service 1, 2 Sensor 1 Trim 1, 2, 2, 1
Filter 50/60 Hz 1, 3, 5, 1 Sensor 1 Trim-Factory 1, 2, 2, 1, 2
Hardware Rev 1, 4, 1 Sensor Type 1, 3, 2, 1, 1
Hart Output 1, 3, 3, 3 Software Revision 1, 4, 1
Intermittent Detect 1, 3, 5, 4 Status 1, 2, 1, 4
LCD Display Options 1, 3, 3, 4 Tag 1, 3, 4, 1
Loop Test 1, 2, 1, 1 Terminal Temperature 1, 3, 2, 2,
LRV (Lower Range Value) 1, 1, 6 Test Device 1, 2, 1
LSL (Lower Sensor Limit) 1, 1, 8 URV (Upper Range Value) 1, 1, 7
Measurement Filtering 1, 3, 5 USL (Upper Sensor Limit) 1, 1, 9
Message 1, 3, 4, 4 Variable Mapping 1, 3, 1
Meter Configuring 1, 3, 3, 4, 1 Variable Re-Map 1, 3, 1, 5
Meter Decimal Point 1, 3, 3, 4, 2 Write Protect 1, 2, 3
2-Wire Offset 1, 3, 2, 1, 2, 1
Table B-1. Device Revision 8 and 9 (HART 5 and 7) Field Communicator Device Dashboard Fast Key
Sequences
Function HART 5 HART 7
