26
Reference Manual
00809-0200-4728, Rev SA
Configuration
July 2018
Configuration
Figure 2-16. LOI and LCD Display
Field Communicator
From the HOME screen, enter the Fast Key sequence.
AMS Device Manager
1. Right click on the device and select Configure.
2. In the left navigation pane select Manual Setup.
3. On the Display Tab there will be a group box with all available variables that can be displayed.
4. Check and uncheck the desired display variables, with a checked box indicating that the variable will
be displayed.
5. Select “Apply” when complete.
LOI
Reference Figure 2-17 to find the LCD display value configuration path on the LOI.
LCD display LOI
Device Dashboard Fast Keys
2, 1, 4
