Quick Installation Guide
00825-0100-4727, Rev CC
January 2013
Rosemount 8700 Series
8
Table 2. Flange Bolt Torque and Bolt Load Specifications for 8705 (EN 1092-1)
Polyurethane, Linatex, Adiprene and Neoprene Liners
Size Code
PN10 PN 16 PN 25 PN 40
Line Size (Newton-meter) (Newton-meter) (Newton-meter) (Newton-meter)
005 0.5-inch
(15 mm)
10
010 1 inch
(25 mm)
20
015 1.5 inch
(40 mm)
50
020 2 inch
(50 mm)
60
025 2.5 inch
(65 mm)
50
030 3 inch
(80 mm)
50
040 4 inch
(100 mm)
50 70
050 5.0 inch
(125 mm)
70 100
060 6 inch
(150mm)
90 130
080 8 inch
(200 mm)
130 90 130 170
100 10 inch
(250 mm)
100 130 190 250
120 12 inch
(300 mm)
120 170 190 270
140 14 inch
(350 mm)
160 220 320 410
160 16 inch
(400 mm)
220 280 410 610
180 18 inch
(450 mm)
190 340 330 420
200 20 inch
(500 mm)
230 380 440 520
240 24 inch
(600 mm)
290 570 590 850
