Quick Installation Guide
00825-0100-4004, Rev DB
December 2011
Rosemount 8800D
2
© 2011Rosemount Inc. All rights reserved. All marks property of owner.
Rosemount and the Rosemount logotype are registered trademarks of Rosemount, Inc.
The Emerson logo is a trademark and servicemark of Emerson Electric Co.
This installation guide provides basic guidelines for the Rosemount
®
8800D Vortex
Flowmeter. It does not provide instructions for detailed configuration, diagnostics,
maintenance, service, troubleshooting, Explosion-proof, Flameproof, or Intrinsically Safe
(I.S.) installations. Refer to the Rosemount 8800D reference manual (document number
00809-0100-4004) for more instruction. The manuals and this QIG are also available
electronically on www.rosemount.com.
Explosions could result in death or serious injury:
Installation of this transmitter in an explosive environment must be in accordance with the
appropriate local, national, and international standards, codes, and practices. Please
review the approvals section of the Rosemount 8800D reference manual for any
restrictions associated with a safe installation.
• Before connecting a handheld communicator in an explosive atmosphere, make sure
the instruments in the loop are installed in accordance with intrinsically safe or
non-incendive field wiring practices.
• Verify the operating atmosphere of the flowmeter is consistent with the appropriate
product certifications.
In an Explosion-proof/Flameproof installation, do not remove the flowmeter covers when
power is applied to the unit.
Electrical shock can result in death or serious injury
• Avoid contact with the leads and terminals. High voltage that may be present on leads
can cause electrical shock.
