The ERTune™ Program: Basic Features
CAUTION
If you are modifying a Profile that has been previously downloaded
or saved, you must click the Download button to download the updated
Profile to the ER5000 or the Save button to save the updated Profile to
the PC, when all modifications have been done. Otherwise, the updates
will be lost when you close the ERTune™ program.
A Profile must be downloaded to the ER5000 if you wish to use it to
run the controller.
To add a command line (segment) to a Profile
1. Click within the Prole Window to select a segment of the
current Prole. The new command will be added BEFORE the
segment you select.
2. Select a command from the drop-down Segment Types list.
OR
Click the Ramp, Dwell or Step button. These three commands,
which are the most commonly used Prole segments, can be
accessed directly using these “hot” buttons.
3. The Segment Types Window displays the entry elds to set
the parameter values for the command.
4. Enter or select the values for the command.
5. Click the Insert Button. The command is added to the Prole
Window above the selected segment.
To modify a segment in a Profile
1. Click within the Prole Window to select the segment. It may
be necessary to scroll to locate the segment line.
2. The parameter entry elds will appear in the Segment Type
Window with the current values displayed.
3. Enter the new values.
4. Click the Modify Button. The segment will be updated with
the new values.
To delete a segment from a Profile
5. Click within the Prole Window to select the segment. It may
be necessary to scroll to locate the segment line. Click the
Delete Button. The segment is immediately deleted.
To add comments to a Profile
1. Enter comments in the Prole Comments Block. The
Comments Block is the bottom panel of the Prole Tab.
2. Press the Tab key when you are done.
NOTENOTE
CAUTIONCAUTION
WARNINGWARNING
Each Prole has a single comment block to hold all comments.
To use a Profile to control the ER5000
1. Check that the Prole has been downloaded to the controller.
2. Select Prole in the Setpoint Source eld of the Tuning Tab.
Refer to Selecting a Setpoint Source.
3. Click the Start button.
