ER5000 —
172
The ERTune™ Program: Basic Features
The Acquisition Panel
The entry elds in this panel allow you to set the sample rate and
collection time for the data le.
The Sample Rate entry eld accepts any multiple of 0.1 seconds.
NOTENOTE
CAUTIONCAUTION
WARNINGWARNING
While the minimum sample rate the ERTune™ program can
process is 0.1 seconds, your actual sampling rate may be limited by the
processing power of the PC that is running the program.
The Collection Time entry eld sets the default timeframe for data
collection. The maximum value you can enter is 31,536,000 seconds,
which is 1 year.
To control data collection manually
1. Enter a value in the
Collection Time entry eld that is
considerably higher than your intended collection time. This
will prevent the program from automatically terminating
data collection prematurely.
2. Click the Start DAQ button. The button changes to display Stop
DAQ and data acquisition begins.
3. Click the button again when you wish to end collection. The
button returns to a display of Start DAQ and the data le is
saved to the PC.
