Table 5-19 Cable ratings (200 V)
Table 5-20 Cable ratings (400 V)
The nominal cable sizes below are only a guide. The mounting and grouping of cables
affects their current-carrying capacity, in some cases smaller cables may be acceptable
but in other cases a larger cable is required to avoid excessive temperature or voltage
drop. Refer to local wiring regulations for the correct size of cables.
Model
Cable size (IEC)
mm
2
Cable size (UL)
AWG or Kcmil
Input Output Input Output
Nominal Max
Install
method
Nominal Max
Install
method
Nominal Max Nominal Max
07200610
35
70 B2
35
70 B2
2
1/0
2
1/007200750 1 1
07200830
70
70 1/0 1/0
08201160
95
2 x 70 B2
95
2 x 70 B2
3/0
2 x 1
3/0
2 x 1
08201320 2 x 70 2 x 70 2 x 1 2 x 1
09201760 2 x 70 2 x 185
B1
2 x 95 2 x 150
B2
2 x 2/0 2 x 500 2 x 2/0 2 x 350
09202190 2 x 95 2 x 185 2 x 120 2 x 150 2 x 4/0 2 x 500 2 x 4/0 2 x 350
10202830 2 x 120 2 x 185 B1 2 x 120 2 x 150
C
2 x 250 2 x 500 2 x 250 2 x 350
10203000 2 x 150 2 x 185 C 2 x 120 2 x 150 2 x 300 2 x 500 2 x 250 2 x 350
Model
Cable size (IEC)
mm
2
Cable size (UL)
AWG or Kcmil
Input Output Input Output
Nominal Max
Install
method
Nominal Max
Install
method
Nominal Max Nominal Max
07400660
35
70 B2
35
70 B2
1
1/0
1
1/007400770
50 50
22
07401000
70 70
1/0 1/0
08401340
2 x 50
2 x 70
B2
2 x 50
2 x 70 B2
2 x 1
2 x 1/0
2 x 1
2 x 1/0
08401570
2 x 70 2 x 70
2 x 1/0 2 x 1/0
09402000
2 x 70
2 x 185
B1
2 x 95
2 x 150
B2
2 x 3/0 2 x 500 2 x 2/0 2 x 350
09402240
2 x 95
2 x 185
2 x 120
2 x 150 2 x 4/0 2 x 500 2 x 4/0 2 x 350
10402700
2 x 120
2 x 185
C
2 x 120 2 x 150
C
2 x 300 2 x 500 2 x 250 2 x 350
10403200
2 x 150
2 x 185 2 x 150 2 x 150 2 x 350 2 x 500 2 x 300 2 x 350
