Unidrive M / HS Frame 7 to 10 Power Installation Guide 5
Issue Number: 5
EU Declaration of Conformity
This declaration is issued under the sole responsibility of the manufacturer. The object of the declaration is in
conformity with the relevant Union harmonization legislation. The declaration applies to the variable speed drive
products shown below:
The model number may be followed by additional characters that do not affect the ratings.The variable speed drive
products listed above have been designed and manufactured in accordance with the following European
harmonized standards:
EN 61000-3-2:2014 Applicable where input current < 16 A. No limits apply for professional equipment where input
power ≥1 kW.
These products comply with the Restriction of Hazardous Substances Directive (2011/65/EU), the Low Voltage
Directive (2014/35/EU) and the Electromagnetic Compatibility Directive (2014/30/EU).
These electronic drive products are intended to be used with appropriate motors, controllers, electrical
protection components and other equipment to form complete end products or systems. Compliance with
safety and EMC regulations depends upon installing and configuring drives correctly, including using the
specified input filters.
The drives must be installed only by professional installers who are familiar with requirements for safety
and EMC. Refer to the Product Documentation. An EMC data sheet is available giving detailed information.
The assembler is responsible for ensuring that the end product or system complies with all the relevant
laws in the country where it is to be used.
Control Techniques Ltd
The Gro
Newtown
Powys
UK
SY16 3BE
Moteurs Leroy-Somer
Usine des Agriers
Boulevard Marcellin Leroy
CS10015
16915 Angoulême Cedex 9
France
Model
number
Interpretation Nomenclature aaaa - bbc ddddde
aaaa Basic series
M100, M101, M200, M201, M300, M400, M600, M700, M701, M702, F300,
H300, E200, E300, HS30, HS70, HS71, HS72, M000, RECT
bb Frame size 01, 02, 03, 04, 05, 06, 07, 08, 09, 10, 11
c Voltage rating 1 = 100 V, 2 = 200 V, 4 = 400 V, 5 = 575 V, 6 = 690 V
ddddd Current rating Example 01000 = 100 A
e Drive format
A = 6P Rectifier + Inverter (internal choke), D = Inverter, E = 6P Rectifier +
Inverter (external choke),
T = 12P Rectifier + Inverter (external choke)
EN 61800-5-1:2007
Adjustable speed electrical power drive systems - Part 5-1: Safety requirements -
Electrical, thermal and energy
EN 61800-3: 2004+A1:2012
Adjustable speed electrical power drive systems - Part 3: EMC requirements and
specific test methods
EN 61000-6-2:2005
Electromagnetic compatibility (EMC) - Part 6-2: Generic standards - Immunity for
industrial environments
EN 61000-6-4: 2007+A1:2011
Electromagnetic compatibility (EMC) - Part 6-4: Generic standards - Emission
standard for industrial environments
EN 61000-3-2:2014
Electromagnetic compatibility (EMC) - Part 3-2: Limits for harmonic current
emissions (equipment input current ≤16 A per phase)
EN 61000-3-3:2013
Electromagnetic compatibility (EMC) - Part 3-3: Limitation of voltage changes,
voltage fluctuations and flicker in public, low voltage supply systems, for
equipment with rated current ≤16 A per phase and not subject to conditional
connection
G Williams
Vice President, Technology
Date: 17th March 2016
