Dec la ra t io n o f Co nf orm it y
(including 2006 Machinery Directive)
This declaration is issued under the sole responsibility of the manufacturer. The object of the declaration is in
conformity with the relevant Union harmonization legislation. The declaration applies to the variable speed drive
products shown below:
The model number may be followed by additional characters that do not affect the ratings.
This declaration relates to these products when used as a safety component of a machine. Only the Safe
Torque Off function may be used for a safety function of a machine. None of the other functions of the drive
may be used to carry out a safety function.
These products fulfil all the relevant provisions of the Machinery Directive 2006/42/EC and the Electromagnetic
Compatibility Directive (2014/30/EU).
EC type examination has been carried out by the following notified body:
TUV Rheinland Industrie Service GmbH
Am Grauen Stein
D-51105 Köln
Germany
EC type-examination certificate numbers:
01/205/5270.01/14 dated 2014-11-11
01/205/5387.01/15 dated 2015-01-29
01/205/5383.02/15 dated 2015-04-21
Notified body identification number: 0035
The harmonized standards used are shown below:
Control Techniques Ltd
The Gro
Newtown
Powys
UK
SY16 3BE
Moteurs Leroy-Somer
Usine des Agriers
Boulevard Marcellin Leroy
CS10015
16915 Angoulême Cedex 9
France
Model
number
Interpretation Nomenclature aaaa - bbc ddddde
aaaa Basic series
M300, M400, M600, M700, M701, M702, F300, H300, E200, E300, HS30,
HS70, HS71, HS72, M000, RECT
bb Frame size 01, 02, 03, 04, 05, 06, 07, 08, 09, 10, 11
c Voltage rating 1 = 100 V, 2 = 200 V, 4 = 400 V, 5 = 575 V, 6 = 690 V
ddddd Current rating Example 01000 = 100 A
e Drive format
A = 6P Rectifier + Inverter (internal choke), D = Inverter, E = 6P Rectifier +
Inverter (external choke), T = 12P Rectifier + Inverter (external choke)
EN 61800-5-1:2007
Adjustable speed electrical power drive systems - Part 5-1: Safety requirements
- Electrical, thermal and energy
EN 61800-5-2:2007
Adjustable speed electrical power drive systems - Part 5-2: Safety requirements
- Functional
EN ISO 13849-1:2008
Safety of Machinery, Safety-related parts of control systems, General principles
for design
EN ISO 13849-2:2008 Safety of machinery, Safety-related parts of control systems. Validation
EN 61800-3: 2004+A1:2012
Adjustable speed electrical power drive systems - Part 3: EMC requirements
and specific test methods
EN 62061:2005
Safety of machinery, Functional safety of safety related electrical, electronic
and programmable electronic control systems
