Unidrive M / HS Frame 7 to 10 Power Installation Guide 33
Issue Number: 5
Safety information Product information
Mechanical installation
Electrical installation Technical data UL listing information
Where:
V Air-flow in m
3
per hour (1 m
3
/hr = 0.59 ft
3
/min)
T
ext
Maximum expected temperature in °C outside the enclosure
T
int
Maximum permissible temperature in °C inside the enclosure
P Power in Watts dissipated by all heat sources in the enclosure
k Ratio of
Where:
P
0
is the air pressure at sea level
P
I
is the air pressure at the installation
Typically use a factor of 1.2 to 1.3, to allow also for pressure-drops in dirty air-filters.
Example
To calculate the size of an enclosure for the following:
• Three drives operating at the Normal Duty rating
• External EMC filter for each drive
• Braking resistors are to be mounted outside the enclosure
• Maximum ambient temperature inside the enclosure: 40 °C
• Maximum ambient temperature outside the enclosure: 30 °C
For example, dissipation of each drive: 101 W and dissipation of each external EMC filter: 6.9 W
(max).
Total dissipation: 3 x (101 + 6.9) = 323.7 W
Insert the following values:
T
int
40 °C
T
ext
30 °C
k 1.3
P 323.7 W
Then:
= 126.2 m
3
/hr (74.5 ft
3
/min) (1 m
3
/ hr = 0.59 ft
3
/min)
P
o
P
l
-------
V
31.3× 323.7×
40 30–
---------------------------------------=
Unidrive M frame7 to 10 Power Installation Guide issue5.book Page 33 Tuesday, May 24, 2016 11:52 AM
