3.9.2 EMC filter ratings
Table 3-6 Optional external EMC filter details
* At 55 °C (131 °F).
3.9.3 Overall EMC filter dimensions
Table 3-7 Optional external EMC filter dimensions
CT part
number
Maximum
continuous
current
Voltage
rating
IP
rating
Power dissipation
at rated current
Ground leakage
Discharge
resistors
Balanced
supply
phase-to-
phase and
phase-to-
ground
Worst
case@ 40 °C
(104 °F)
@ 50 °C
(122 °F)
IEC UL
@ 40 °C
(104 °F)
@ 50 °C
(122 °F)
A A V V W W mA mA MΩ
4200-1132 117 102.7* 528 480
20
50 43.7 11.7 188 1.68
4200-0672 67 58.8* 759 600 25 21.9 24.5 395 2.72
4200-1972 197 172.8* 528 480 42 36.7 18.7 210 1.68
4200-1662 114 100* 759 600 39 34.1 24.3 364 2.72
4200-3021 302 277 528 480
00
34 29.7 30 202 1.68
4200-1660 166 152 759 600 13 11.4 21 332 2.72
4200-4460 446 409 528 480 37 32.4 30 283 1.68
4200-2210 221 203 759 600 16 14.0 21 434 2.72
Part Number
Dimensions (mm)
Weight
HW D
mm inch mm inch mm inch kg lb
4200-1132 270 10.63 90 3.54 150 5.90 6 13.2
4200-0672 270 10.63 90 3.54 150 5.90 6.2 13.7
4200-1972 300 11.81 120 4.72 170 6.69 9.6 21.2
4200-1662 300 11.81 120 4.72 170 6.69 9.4 20.7
4200-3021 339 13.3 230 9.06 120 4.72 11 24.3
4200-1660 360 14.2 245 9.6 105 4.13 5.2 11.5
4200-4460 105 4.13 360 14.2 245 9.6 12 26.5
4200-2210 105 4.13 360 14.2 245 9.6 10.3 22.7
