Unidrive M / HS Frame 7 to 10 Power Installation Guide 43
Issue Number: 5
Safety information Product information
Mechanical installation
Electrical installation Technical data UL listing information
Figure 3-20 External EMC filter (size 9E and 10E)
Table 3-11 Size 9E and 10E external EMC filter dimensions
3.9.4 EMC filter torque settings
Table 3-12 Optional external EMC Filter terminal data.
CT part
number
ABCDEGHWY
4200-4460
280 mm
(11.02)
180 mm
(7.09)
57 mm
(2.24 mm)
245 mm
(9.65 in)
225 mm
(8.86 in)
40 mm
(1.57 in)
105 mm
(4.13 in)
360 mm
(14.7 in)
11 mm
(0.43 in)
4200-2210
CT part
number
Power
connections
Ground
connections
Bar hole diameter Max cable size Max torque
Ground stud
size
Max torque
4200-1132
N/A
50 mm
2
(1/0 AWG)
8.0 N m
(6.0lb ft)
M10
18 N m
(13.3 lb ft)
4200-0672
4200-1972
95 mm
2
(3/0 AWG)
20 N m
(14.8 lb ft)
4200-1662
4200-3021 10.8 mm
N/A
30 N m
(22.1 lb ft)
4200-1660 10.8 mm
4200-4460 11 mm
4200-2210 11 mm
V: Ground stud - M10
Z: O 11 mm
Unidrive M frame7 to 10 Power Installation Guide issue5.book Page 43 Tuesday, May 24, 2016 11:52 AM
