52 Unidrive M / HS Frame 7 to 10 Power Installation Guide
Issue Number: 5
Figure 4-2 Frame 9A power and ground connections
Input connections
Mains
Supply
L1 L2
Optional
EMC filter
Fuses
L3
L1 L2 L3
PE
Supply
ground
+DC -DC
UVW
Motor
Optional ground
connection
+DC BR
Thermal
overload
protection
device
Output connections
*
Internal EMC
filter
9A9A
Unidrive M frame7 to 10 Power Installation Guide issue5.book Page 52 Tuesday, May 24, 2016 11:52 AM
