58 Unidrive M / HS Frame 7 to 10 Power Installation Guide
Issue Number: 5
Table 4-4 Input line reactor ratings (2 %)
4.2.3 Input inductor calculation
To calculate the inductance required (at Y %), use the following equation:
Where:
I = drive rated input current (A)
L = inductance (H)
f = supply frequency (Hz)
V = voltage between lines
Part
number
Model
Current Inductance
Overall
width
(W)
Overall
depth
(D)
Overall
height
(H)
Weight
Max
ambient
temp
Min
airflow
Maximum
losses
Quantity
required
A μHmmmmmmkg°Cm/sW
4401-0223 INL 5006 47 480 255 130 210 12.5 50 0 122 1
4401-0227 INL 2009 67 130 206 130 160 6.9 50 0 90 1
4401-0228 INL 2010 88 100 206 140 160 9 50 0 97 1
4401-0229 INL 2011 105 80 206 140 160 9.5 50 0 90 1
4401-0230 INL 2012 137 62 254 130 195 12.5 50 0 143 1
4401-0231 INL 2013 166 51 254 150 195 14 50 0 137 1
4401-0237 INL 4014 74 200 254 130 195 12 50 0 129 1
4401-0238 INL 4015 88 170 254 150 195 14 50 0 127 1
4401-0239 INL 4016 105 140 254 150 195 14 50 0 139 1
4401-0240 INL 4017 155 95 290 160 205 20 50 0 182 1
4401-0241 INL 4018 177 83 290 170 205 22 50 0 200 1
4401-0245 INL 5010 67 340 290 150 205 18 50 0 139 1
4401-0246 INL 5011 88 250 290 170 205 22 50 0 147 1
4401-0247 INL 5012 105 200 290 180 225 25 50 0 167 1
4401-0248 INL 6001 20 1270 206 95 200 5.8 50 0 71 1
4401-0249 INL 6002 26 980 206 130 200 7.4 50 0 80 1
4401-0250 INL 6003 32 880 206 140 200 10 50 0 84 1
4401-0251 INL 6004 39 650 254 130 210 12 50 0 123 1
4401-0252 INL 6005 45 580 254 130 210 12.5 50 0 124 1
4401-0253 INL 6006 67 410 290 150 205 18 50 0 123 1
4401-0254 INL 6007 88 300 290 170 205 22 50 0 169 1
4401-0255 INL 6008 105 240 290 180 225 25 50 0 204 1
4401-0181 INL 401 245 63 240 190 225 32 50 1 148 1
4401-0182 INL 402 370 44 276 200 225 36 50 1 205 1
4401-0183 INL 601 145 178 240 190 225 33 50 1 88 1
4401-0184 INL 602 202 133 276 200 225 36 50 1 116 1
L
Y
100
----------
V
3
-------
×
1
2πfI
------------
×=
