72 Unidrive M / HS Frame 7 to 10 Power Installation Guide
Issue Number: 5
Table 4-8 EMC filter cross reference
4.11.1 Grounding hardware
The drive is supplied with a grounding bracket to facilitate EMC compliance. They provide a
convenient method for direct grounding of cable shields without the use of "pig-tails”. Cable shields
can be bared and clamped to the grounding bracket using metal clips or clamps
1
(not supplied) or
cable ties. Note that the shield must in all cases be continued through the clamp to the intended
terminal on the drive, in accordance with the connection details for the specific signal.
1
A suitable clamp is the Phoenix DIN rail mounted SK14 cable clamp (for cables with a maximum
outer diameter of 14 mm).
• See Figure 4-12 for details on installing the grounding bracket.
Model CT part number
200 V
07200610 to 07200830 4200-1132
08201160 to 08201320 4200-1972
09201760 to 09202190 (9A) 4200-3021
09201760 to 09202190 (9E) 4200-4460
10202830 to 10203000 4200-4460
400 V
07400660 to 07401000 4200-1132
08401340 to 08401570 4200-1972
09402000 to 09402240 (9A) 4200-3021
09402000 to 09402240 (9E) 4200-4460
10402700 to 10403200 4200-4460
575 V
07500440 to 07500550 4200-0672
08500630 to 08500860 4200-1662
09501040 to 09501310 (9A) 4200-1660
09501040 to 09501310 (9E) 4200-2210
10501520 to 10501900 4200-2210
690 V
07600190 to 07600540 4200-0672
08600630 to 08600860 4200-1662
09601040 to 09601310 (9A) 4200-1660
09601040 to 09601310 (9E) 4200-2210
10601500 to 10601780 4200-2210
High ground leakage current
When an EMC filter is used, a permanent fixed ground connection must be provided which
does not pass through a connector or flexible power cord. This includes the internal EMC
filter.
The installer of the drive is responsible for ensuring compliance with the EMC regulations
that apply where the drive is to be used.
