82 Unidrive M / HS Frame 7 to 10 Power Installation Guide
Issue Number: 5
Avoid placing sensitive signal circuits in a zone 300 mm (12 in) all around the power module.
Figure 4-20 Sensitive signal circuit clearance
³300mm
(12in)
Sensitive
signal
cable
