Unidrive M / HS Frame 7 to 10 Power Installation Guide 89
Issue Number: 5
Safety information Product information Mechanical installation Electrical installation
Technical data
UL listing information
Table 5-3 575 V drive ratings (500 V to 575 V ±10 %)
Table 5-4 690 V drive ratings (500 V to 690 V ±10 %)
Model
Normal Duty Heavy Duty
Max
cont
output
current
Nominal
power at
575 V
Motor
power at
575 V
Peak
current
Max
cont
output
current
Open
loop
peak
current
R F C
peak
current
Nominal
power at
575 V
Motor
power at
575 V
AkWhp A AAAkWhp
07500440
53 45 50 58.3 44 66 88 30 40
07500550
73 55 60 80.3 55 82.5 110 37 50
08500630
86 75 75 94.6 63 94.5 126 45 60
08500860
108 90 100 118.8 86 129 172 55 75
09501040
125 110 125 137.5 104 156 182 75 100
09501310
150 110 150 165 131 196.5 229.25 90 125
10501520
200 130 200 220 152 228 266 110 150
10501900
200 150 200 220 190 285 332.5 132 200
Model
Normal Duty Heavy Duty
Max
cont
output
current
Nominal
power at
690 V
Motor
power at
690 V
Peak
current
Max
cont
output
current
Open
loop
peak
current
R F C
peak
current
Nominal
power at
690 V
Motor
power at
690 V
AkWhpA AAAkWhp
07600190
23 18.5 25 25.3 19 28.5 38 15 20
07600240
30 22 30 33 24 36 48 18.5 25
07600290
36 30 40 39.6 29 43.5 58 22 30
07600380
46 37 50 50.6 38 57 76 30 40
07600440
52 45 60 57.2 44 66 88 37 50
07600540
73 55 75 80.3 54 81 108 45 60
08600630
86 75 100 94.6 63 94.5 126 55 75
08600860
108 90 125 118.8 86 129 172 75 100
09601040
125 110 150 137.5 104 156 182 90 125
09601310
155 132 175 170.5 131 196.5 229.25 110 150
10601500
172 160 200 189.2 150 225 262.5 132 175
10601780
197 185 250 216.7 178 267 311.5 160 200
