Unidrive M / HS Frame 7 to 10 Power Installation Guide 91
Issue Number: 5
Safety information Product information Mechanical installation Electrical installation
Technical data
UL listing information
* For Unidrive M200 to M400 the 0.667 and 1 kHz value is the same as the 2 kHz value.
10501900 150 200 200 152 116 76 54 132 200 190 190 186 137 106 70 51
690 V
07600190 18.5 25 23 21.2 15 20 19 16.7
07600240 22 30 30 27.9 21.2 18.5 25 24 21.8 16.6
07600290 30 40 36 28.1 21.2 22 30 29 21.8 16.5
07600380 37 50 46 40.5 28.1 21.2 30 40 38 30.8 21.7 16.7
07600440 45 60 52 51.5 40.6 28.1 21.2 37 50 44 38.7 30.8 21.6 16.7
07600540 55 75 73 71.5 51.8 40.6 28.1 21.2 45 60 54 52.9 39 31 21.6 16.7
08600630 75 100 86 72.2 49.7 37.8 55 75 63 53.3 37 28.4
08600860 90 125 108 91.8 72.4 49.7 37.8 75 100 86 67.1 53.3 37 28.4
09601040 110 150 125 100 71 54 90 125 104 85 61 47
09601310 132 175 155 126 100 71 54 110 150 131 105 85 62 47
10601500 160 200 172 169 126 100 71 55 132 175 150 138 105 86 62 47
10601780 185 250 197 154 114 75 55 160 200 178 137 105 69 52
Model
Normal Duty Heavy Duty
Nominal
rating
Maximum permissible continuous
output current (A) for the following
switching frequencies
Nominal
rating
Maximum permissible continuous
output current (A) for the following
switching frequencies
kW hp
2
kHz*
3
kHz
4
kHz
6
kHz
8
kHz
12
kHz
16
kHz
kW hp
2
kHz*
3
kHz
4
kHz
6
kHz
8
kHz
12
kHz
16
kHz
Unidrive M frame7 to 10 Power Installation Guide issue5.book Page 91 Tuesday, May 24, 2016 11:52 AM
