Table 5-9 Power losses from the front of the drive when through-panel mounted
5.1.4 Temperature, humidity and cooling method
Ambient temperature operating range:
- 20 °C to 55 °C (- 4 °F to 131 °F).
Output current derating must be applied at ambient temperatures >40 °C (104 °F).
Cooling method: Forced convection
Maximum humidity: 95 % non-condensing at 40 °C (104 °F)
09501040 (9E) 1595 1865 2135 2443 2392 2460 2674 1290 1519 1748 2067 2072 2229 2436
09501310 (9E) 1933 2256 2580 2448 2392 2447 2652 1630 1913 2109 2071 2078 2229 2434
10501520 2692 2841 2654 2448 2392 2447 2652 1917 2220 2112 2077 2083 2222 2452
10501900 2384 2797 3141 2743 2672 2766 3036 2213 2605 2686 2516 2496 2651 2933
690 V
07600190 359 428 491 617 743 750 758 301 360 413 519 625 631 638
07600240 463 551 631 791 958 968 977 373 446 513 644 776 784 792
07600290 554 660 754 944 1144 1155 1167 446 533 610 765 809 817 825
07600380 717 854 965 1206 1144 1155 1167 583 697 796 926 885 894 903
07600440 814 969 1094 1225 1144 1155 1167 683 817 923 933 885 894 903
07600540 1029 1225 1228 1098 1030 1040 1051 758 906 908 837 797 805 813
08600630 1553 1850 2172 2540 2672 2699 2726 1125 1345 1585 2292 2229 2251 2274
08600860 1755 2090 2291 2540 2684 2711 2738 1543 1845 2029 2039 2014 2034 2054
09601040 (9A) 1878 2213 2548 2933 2882 2974 3248 1513 1798 2083 2483 2502 2721 2994
09601310 (9A) 2384 2797 3175 2918 2855 2974 3249 1931 2281 2548 2488 2509 2718 2991
09601040 (9E) 1730 2065 2400 2810 2803 2934 3223 1409 1694 1979 2392 2443 2690 2974
09601310 (9E) 2160 2573 2955 2796 2778 2934 3225 1769 2119 2395 2397 2450 2687 2972
10601500 2420 2882 2947 2805 2789 2932 3229 2042 2441 2403 2377 2467 2701 2974
10601780 2614 3132 3610 3243 3221 3420 3771 2305 2774 3111 3007 2996 3253 3621
Frame size Power loss
7 ≤ 204 W
8 ≤ 347 W
9 ≤ 480 W
10 ≤ 480 W
Model
Normal Duty Heavy Duty
Drive losses (W) taking into account any
current derating for the given conditions
Drive losses (W) taking into account any current
derating for the given conditions
2
kHz*
3
kHz
4
kHz
6
kHz
8
kHz
12
kHz
16
kHz
2
kHz*
3
kHz
4
kHz
6
kHz
8
kHz
12
kHz
16
kHz
