Electronic Bypass Controller Installation and Commissioning Guide 5
Section 1 - Introduction
Thank you for purchasing your Emerson Control Techniques electronic bypass
package. This manual provides information concerning the installation, wiring
and general startup procedures for both the HVAC Drive H300, Unidrive M200
and Unidrive M400 lines of electronic bypass packages. The electronic bypass is
a complete integrated HVAC control system which employs the latest Variable
Frequency Drive (VFD) technology and incorporates a dedicated micro-processor
based controller for HVAC applications. The electronic bypass package uses a
dedicated electronic bypass keypad that clearly shows the system operating status.
The electronic bypass is designed for ease of installation and startup.
Please follow this instruction manual’s guidelines for proper installation and
programming of your electronic bypass package.
HVAC Drive H300
Unidrive M200
Unidrive M400
Electronic bypass keypad
Lower enclosure
Disconnect handle
