Interface Tag Description
BOOL_OUT[2].1 (A034) Alarm:
BOOL_OUT[2].2 (A035) Alarm:
BOOL_OUT[2].3 (A036) Alarm:
BOOL_OUT[2].4 (A037) Alarm:
BOOL_OUT[2].5 (A038) Alarm:
BOOL_OUT[2].6 (A039) Alarm:
BOOL_OUT[2].7 (A040) Alarm: Blower 2 - High Discharge Temperature
BOOL_OUT[2].8 (A041) Alarm: Blower 2 - High Discharge Pressure
BOOL_OUT[2].9 (A042) Alarm: Blower 2 - Low Suction Pressure
BOOL_OUT[2].10 (A043) Alarm: Blower 2 - High Phase A Temperature
BOOL_OUT[2].11 (A044) Alarm: Blower 2 - High Phase B Temperature
BOOL_OUT[2].12 (A045) Alarm: Blower 2 - High Phase C Temperature
BOOL_OUT[2].13 (A046) Alarm: Blower 2 - High ODE Bearing Temperature
BOOL_OUT[2].14 (A047) Alarm: Blower 2 - High DE Bearing Temperature
BOOL_OUT[2].15 (A048) Alarm: Blower 2 - High Motor Amps
BOOL_OUT[2].16 (A049) Alarm: Blower 2 - VFD Speed Reference Fault
BOOL_OUT[2].17 (A050) Alarm: Blower 2 - Oil Cooler Fan Fault
BOOL_OUT[2].18 (A051) Alarm:
BOOL_OUT[2].19 (A052) Alarm:
BOOL_OUT[2].20 (A053) Alarm:
BOOL_OUT[2].21 (A054) Alarm:
BOOL_OUT[2].22 (A055) Alarm:
BOOL_OUT[2].23 (A056) Alarm:
BOOL_OUT[2].24 (A057) Alarm:
BOOL_OUT[2].25 (A058) Alarm:
BOOL_OUT[2].26 (A059) Alarm:
BOOL_OUT[2].27 (A060) Alarm: Blower 3 - High Discharge Temperature
BOOL_OUT[2].28 (A061) Alarm: Blower 3 - High Discharge Pressure
BOOL_OUT[2].29 (A062) Alarm: Blower 3 - Low Suction Pressure
BOOL_OUT[2].30 (A063) Alarm: Blower 3 - High Phase A Temperature
BOOL_OUT[2].31 (A064) Alarm: Blower 3 - High Phase B Temperature
BOOL_OUT[3].0 (A065) Alarm: Blower 3 - High Phase C Temperature
BOOL_OUT[3].1 (A066) Alarm: Blower 3 - High ODE Bearing Temperature
BOOL_OUT[3].2 (A067) Alarm: Blower 3 - High DE Bearing Temperature
BOOL_OUT[3].3 (A068) Alarm: Blower 3 - High Motor Amps
BOOL_OUT[3].4 (A069) Alarm: Blower 3 - VFD Speed Reference Fault
BOOL_OUT[3].5 (A070) Alarm: Blower 3 - Oil Cooler Fan Fault
BOOL_OUT[3].6 (A071) Alarm:
BOOL_OUT[3].7 (A072) Alarm:
BOOL_OUT[3].8 (A073) Alarm:
BOOL_OUT[3].9 (A074) Alarm:
