Figure 3-1: Installing
To remove the unit, see Figure 3-2.
3. Place a flat or rounded object (such as a screw driver) into the DIN clip and apply a
slight pressure downwards on the object.
4. Once the unit is released from the DIN rail pull backwards and down to successfully
disengage.
Figure 3-2: Removing
