Table 5-2: Predefined Modbus Registers (continued)
Description Register Data type
SYSTEM_DIAG.ADDITIONAL_STATUS_3 49018 8-bit unsigned int
SYSTEM_DIAG.ADDITIONAL_STATUS_4 49019 8-bit unsigned int
SYSTEM_DIAG.ADDITIONAL_STATUS_5 49020 8-bit unsigned int
SYSTEM_DIAG.ADDITIONAL_STATUS_6 49021 8-bit unsigned int
SYSTEM_DIAG.ADDITIONAL_STATUS_7 49022 8-bit unsigned int
SYSTEM_DIAG.ADDITIONAL_STATUS_8 49023 8-bit unsigned int
SYSTEM_DIAG.ADDITIONAL_STATUS_9 49024 8-bit unsigned int
SYSTEM_DIAG.ADDITIONAL_STATUS_10 49025 8-bit unsigned int
SYSTEM_DIAG.ADDITIONAL_STATUS_11 49026 8-bit unsigned int
SYSTEM_DIAG.ADDITIONAL_STATUS_12 49027 8-bit unsigned int
SYSTEM_DIAG.UNREACHABLE 49028 32-bit int
SYSTEM_DIAG.UPTIME 49029 32-bit int
SYSTEM_DIAG.TEST_BOOLEAN 49031 Boolean
SYSTEM_DIAG.TEST_BYTE 49032 8-bit int
SYSTEM_DIAG.TEST_UNSIGNED_BYTE 49033 8-bit unsigned int
SYSTEM_DIAG.TEST_SHORT 49034 16-bit int
SYSTEM_DIAG.TEST_UNSIGNED_SHORT 49035 16 -bit unsigned int
SYSTEM_DIAG.TEST_INT 49036 32-bit int
SYSTEM_DIAG.TEST_UNSIGNED_INT 49038 32-bit unsigned int
SYSTEM_DIAG.TEST_FLOAT 49040 32-bit float
5.5 EtherNet/IP
5.5.1 Communication settings
It is important that the EtherNet/IP communication settings in the Gateway match the
setting in the EtherNet/IP master or client. Refer to the host system documentation for
more information on how to configure these settings, or to the reference manual for the
EtherNet/IP (document number 00809-0500-4420). The EtherNet/IP communication
settings can be found by navigating to:
System Settings → Protocols → Ethernet/IP
Note
EtherNet/IP can be integrated with any approved EtherNet/IP ODVA member. Other
protocols such as HART-IP
™
are still functional within the Gateway. Consult the Product
Data Sheet (document number 00813-0200-4420) for ordering options.
Operation and Maintenance Reference Manual
September 2020 00809-0200-4410
40 Emerson.com/Rosemount
