16
SINGLE-ZONE OPERATION CHARTS
Heat Pump use Common Suction Port - Straight Cool only use Common Discharge Port.
0
4
8
12
50
90
130
170
210
210
270
330
390
450
510
65 75 85 95 105 115
Outdoor Temp (
°
F)
Compressor Subcool (
°
F)
Low Pressure (psig)
High Pressure (psig)
Cooling Cycle
Model S1CV8000 &S1HV8000
with WLHV18 or UNHVG18 (R-410A Ref.)
Room Temp (
°
F)
Relative Humidity 50%
85
°
F
80
°
F
75
°
F
Condenser
0
4
8
12
50
90
130
170
210
210
270
330
390
450
510
65 75 85 95 105 115
Outdoor Temp (
°
F)
Compressor Subcool (
°
F)
Low Pressure (psig)
High Pressure (psig)
Cooling Cycle
Model S1CV8000 & S1HV8000
with CAHV18 (R-410A Ref.)
Room Temp (
°
F)
Relative Humidity 50%
85
°
F
80
°
F
75
°
F
Condenser
Performance data listed is subject to change without notice. For most current unit/system performance data, refer to EMI listing of
VSMS certifi ed products in the AHRI directory, at www.ahridirectory.org.
