Equipment Use
Electrical control equipment for generating sets
Housing & Mounting 72 mm x 72 mm x 52 mm
Panel Cut-out
68 mm x 68 mm
Protection
NEMA4X (IP30 at front panel, IP20 at rear side)
Weight
Approximately 0.5 kg
Environmental Rating
Standard, indoor at an altitude of less then 2000 meters with non-condensing humidity
Operating / Storage Temperature
-25ºC to +70ºC / -40ºC to +85ºC
Operating / Storage Humidity
90% max. (Non-condensing)
Installation Over Voltage Cat.
II appliances, portable equipment
Pollution Degree
II, Normal office or workplace, non-conductive pollution
Mode of Operation
Continuous
EMC EN-61000-6-4, EMC generic emission standard for industrial equipment
EN-61000-6-2, EMC generic immunity standard for industrial equipment
Electrical Safety EN-61010-1, safety requirements for electrical equipment for measurement, control and
laboratory use
Supply Voltage(Z)
Cranking Dropouts Battery voltage can be 0VZ for max. 100msn during cranking (battery voltage should be
at least nominal voltage before cranking)
Failure Indicators
Status Indicators
Relay Outputs
8 - 32 VZ
0.5%
Alternator Frequency Range
From generator voltageGenerator Speed Measurement
Start relay (10A@28VZ)
Fuel relay (10A@28VZ)
Conf. Out relay (10A@28VZ)
Failed to engine start
High engine temperature
Low oil pressure
Speed failure
Battery charge failure
General failure
Hz./RPM
Engine running time
Engine start
Engine stop
Frequency Meas. Accuracy
15,6 to 99,9 Hz (15 to 300 VL-NV RMS)
Specifications
3
Manual and Remote Start Unit with Key Switch, 72x72 DIN Size
