Assembly and usage of chassis
Emmaljunga Adjustable Comfort System
• To maximize the comfort for the child you can adjust the angle on the
pram body/seat unit.
How to use the Adjustable Comfort System
• The Adjustable Comfort System on the chassis enables you to adjust
the angle on the pram body/seat unit.
• The angle may be adjusted into three different positions.
1. Low
2. Medium
3. High
WARNING
• Remove your child from the pram before adjusting the angle.
Important
• Adjust the tilt when the chassis is folded to avoid unnecessary
wearing of the mechanism.
• Adjust the angle by pulling the grey tab (10) outwards and
twist the knob until the grey button locks into the desired position:
1, 2 or 3. Repeat on the other side of the chassis - make sure the
knobs are in the same positions on both sides of the chassis.
WARNING
• The angle must be in the same position on both sides of the
chassis to avoid uneven strain and possible damage to the chassis.
Thefrontwheelcanbexedorswivel360degrees.
• The wheels are xed by pressing the locking ring (11) down when
the wheels are positioned straight forward.
• The wheels can rotate freely 360 degrees by pulling the locking ring
up.
How to adjust the height of the handle
• Adjust the height by pressing the grey buttons on the inside of the
handle (8). Keep the buttons pressed in while you adjust the handle
to the required position (9).
Removing front wheels from cahssis.
(Onlyforchassiswithremovablefrontwheels.)
• Depress the release button (12) and pull out the front wheel (13) .
