GB | Wireless Thermostat with OpenTherm
Communication
The P5616OT thermostat is designed for controlling heating and air-con-
ditioning systems.
Important
• Before the rst use, make sure to carefully read the operating
manual for the thermostat, as well as the manual for the boiler or
air-conditioning equipment.
• Turn o power supply before installing the thermostat!
• Installation should be carried out by qualied personnel!
• During installation, observe the prescribed standards.
Technical specications
Switched load: max. 230 V AC; 10 A for resistive load; 4 A for inductive
load
Temperature measurement: 0 °C to 40 °C with 0.1 °C resolution
accuracy ±1 °C at 20 °C
Temperature setting: 5 °C to 35 °C in 0.5 °C increments
Dierential setting: 0.2 °C to 2 °C, in 0.1 °C increments
Power supply:
Control unit with display (transmitter): 2× 1.5 V type AA (LR6)
battery
Clock back-up power supply: 1× 3 V type CR2032 battery
Switching unit (receiver): 230 V AC
Unit interconnection: via 868 MHz radio signal, 25 mW e.r.p. max.
Transmitter unit range: up to 80 m in an open area
Dimensions and weight:
Control unit: 126 × 84 × 26 mm; 180 g
Switching unit: 86 × 86 × 36 mm; 146 g
Accessories: 2 screws, 2 wall plugs
Description of Control Elements (See Fig. 1)
1 – Home (return to home screen)
2 – Next (move to the next option within the current function)
3 – Adjust value setting
4 – Conrm (conrm function selection)
5 – Copy
6 – Holiday mode
7 – Battery compartment
8 – Time and date setting
9 – Select and edit programme (PROG)

Emos P5616OT Specifications

General

Frequency	868 MHz
Interface	AC
Child lock	Yes
Proper use	Room
Control type	Buttons
Product color	White
Memory function	No
Units of measurement	°C
Temperature increment	0.5 °C
Temperature setpoint range	5 - 35 °C
Battery type	AA
Power source	AC/Battery
Battery voltage	1.5 V
Operating voltage	230 V
Maximum switching current	10 A
Number of batteries supported	2

Weight and Dimensions

Depth	26 mm
Width	86 mm
Receiver dimensions (WxDxH)	86 x 26 x 86 mm
Bridge dimensions (W x D x H)	126 x 26 x 84 mm
