Programmable Electronic Room
Thermostat • model ST201
ST201 programmable thermostat provides electronic control of 230VAC heating
or cooling system as well as providing a frost protection. ST201 includes feature of
setback function for energy saving purpose. Also it o ers the option of Pulse width
modulation (PWM) control.
ST201 provides 9 prede ned and user adjustable programs. ST201 has been designed
to give you an easy–to-use and push-button climate control. The large, clear and backlit
display is easy to read even in the dark.
GB
Speci cations
Dimensions 135 (W) x 105 (H) x 32 (D) mm
Materials Polycarbonate (PC)
Weight 300 g
Battery Alkaline AA 1.5 V x 2
Max. Switching voltage ~ 230 V AC/50 Hz
Max. Switching current ~ 3(1) A
Temperature control range 10 -35 °C
Temperature Control Span 0.5/1/2 °C
Operating temperature 0 °C - 50 °C
Storage temperature -20 °C - 60 °C
Keys
ST201 has 8 input keys: COMF/ECON, U, V, PROG, OK, green Button, SET, and internal
RESET Button.
Keys Functions
COMF/ECON Select Comfort, Econ or Defrost set-temp
U and V
Adjust the desired set-temperature
PROG
Cancel program override/ select program in
program setting mode
OK Return to normal mode
Green Button
Turn on setback function in heating system/
switch to o mode in cooling system
SET
Enter setting modes/ change program day in
program setting mode
RESET
Reset the thermostat to default state. This key is
located on the PCB
29
Reset
ST201 will be hard reset after reset button is pressed. ST201 will be soft reset after
power up.
Default of Comfort, Econ and Setback:
• If System option is set to Heat:
Comfort: 21.0 °C (70 °F)
Econ: 19.0 °C (66 °F)
Setback: = Econ – 3 °C (6 °F) = 16.0 °C (60 °F)
• If System option is set to Cool:
Comfort: 24.0 °C (75 °F)
Econ: 27 °C (81 °F)
Function Hard reset Soft reset
Operation mode Normal mode
Temperature scale Depends on option switch
Room temperature The current room temperature
Set-temp Base on the current time and program
Preset Set-temps Default Retrieved from EEPROM
Clock 00:00 Retrieved from EEPROM
Day Monday Retrieved from EEPROM
Program day 5 –2 or 7 – days depends on Program day option
Program pro le
Reset to default (Refer to
„Setting program“)
Retrieved from EEPROM
Program
All days are reset to
Program 1
Retrieved from EEPROM
Program override All cleared
System Heat or Cool mode depends on System option
Control mode
On – O or PWM control depends on Control mode
option
Span Span depends on Span option
Low battery warning Cleared, to be renewed within 4 seconds
LCD backlight O
Short cycle protection
timer
Reset
Power down  ag Reset
Output status
O
Relay is initialized to O
