12
6.4 TWIN-SATELLITE / SUBWOOFER SYSTEM
CD-CHANGER HEAD-UNIT
PRE-OUT FRONT, REAR & SUB
BASS-MIDRANGE
X-OVER X-OVER
TWEETER
X-OVER
X-OVER
BASS-MIDRANGE
TWEETER
BASS-MIDRANGE
TWEETER
BASS-MIDRANGE
TWEETER
CHANNEL 1-CH
CHANNEL 3-CH
CHANNEL 2-CH
CHANNEL 4-CH
CHANNEL
5/6-CH
TRUNKBOX SUBWOOFER
EA 6-CH Manual 12.03.2002 13:32 Uhr Seite 12
