13
6.4 TWIN-SATELLITE / KICKBASS SYSTEM
CD-CHANGER HEAD-UNIT
PRE-OUT FRONT, REAR & SUB
BASS-MIDRANGE
X-OVER X-OVER
TWEETER
X-OVER
X-OVER
BASS-MIDRANGE
TWEETER
BASS-MIDRANGE
TWEETER
BASS-MIDRANGE
TWEETER
CHANNEL 1-CH
CHANNEL 3-CH
CHANNEL 2-CH
CHANNEL 4-CH
KICKBASS
STEREO
CHANNEL 5
CHANNEL 6
EA 6-CH Manual 12.03.2002 13:32 Uhr Seite 13
