6.4 FRONT SATELLITE / KICKBASS/ SUBWOOFER SYSTEM
CD-CHANGER HEAD-UNIT
PRE-OUT FRONT, REAR & SUB
BASS-MIDRANGE
X-OVER X-OVER
TWEETER
BASS-MIDRANGE
TWEETER
CHANNEL 1-CH
CHANNEL 3-CH
CHANNEL 2-CH
CHANNEL 4-CH
KICKBASS
STEREO
CHANNEL
5/6-CH
TRUNKBOX SUBWOOFER
KICKBASS
STEREO
