Select User’s Manual
37
Specifications
Specifications
1 Alternate Ramped Burst (ARB) Rate = 100 pps; Ramp Up Time = 0.5s;
Quick Select Knee Program On Time = 5s; Off Time = 6s; Channel 2 follows
Channel 1; Channel 2 Ramp Up starts at the end
of Channel 1 Ramp Down. Ramp Up starts from 0.
2 Simple Modulated Pulse (SMP) Rate = 125 pps; Cycle Time = 12s; Span
Quick Select Shoulder Program Percentage = 40%; Rate stays in the
2-10 pps range for 1/3 of the cycle time
(4 seconds) as the rate modulates down to
2 pulses per second (pps) and then back
up again.
3 Modulated Amplitude (MA) Rate = 125 pps; Cycle Time = 1s;Span
Quick Select Low Back/Hip Program Percentage = 60%; amplitude modulation
is done through pulse duration modulation;
0.5s intensity is at 100% of set level and
next 0.5s intensity is at 60% (set span percentage
of preset level).
4 Simple Modulated Pulse (SMP) Rate = 125 pps; Cycle Time = 12s; Span
Quick Select Hand/Wrist Program Percentage = 40%; Rate stays in the 2-10 pps
range for 1/3 of the
cycle time (4 seconds) as the
rate modulates down to 2 pulses per second
(pps) and then back up again.
5 Modulated Amplitude (MA) Rate = 125 pps; Cycle Time = 1s; Span
Quick Select Back Program Percentage = 60%; amplitude modulation is done
through pulse duration modulation; 0.5s intensity
is at 100% of set level and next 0.5s intensity is at
60% (set span percentage of preset level).
6 Continuous (C) Rate = 125 pps; Adjustable 2-150 pps in 5 pps
intervals; continuous at set intensity.
7 Burst Rate = 15 pps; Ramp Up Time = 0.4s;
On Time = 1s; Ramp Down Time = 0.5s; 3s of
no stimulation.
8 Simple Modulated Pulse (SMP) Rate = 125 pps; Cycle Time = 12s; Span
Percentage = 40%; Rate stays in the 2-10 pps
range for 1/3 of the cycle time (4 seconds)
as the rate modulates down to 2 pulses per
second (pps) and then back up again.
9 Modulation Rate is pseudo-random between 2, 10, 20,
40, 60, 80, 100, and 150 pps; Cycle Time =
1s;
Span percentage = 50, 58, 66, 75, 83, 91, and
100%; duration is modulated between 7 values
between 50% of set pulse duration and the
set pulse duration.
Program Options Default Parameters Program Options Adjustable Parameters
1 Alternate Ramped Burst (ARB) Intensity (Ch1 and Ch2) = 0-60 in 0.5 intervals
Quick Select Knee Program Duration = 0-400 µs
Rate = 2-150 pps in 5 pps intervals
Cycle Time = 2-20s in 1s intervals
2 Simple Modulated Pulse (SMP) Intensity = 0-60 in 0.5 intervals
Quick Select Shoulder Program Duration = 0-400 µs
Rate = 20-150 pps in 5 pps intervals
Cycle Time = 1-20s in 1s intervals
Span = 20%-95% in 5% intervals
3 Modulated Amplitude (MA) Intensity = 0-60 in 0.5 intervals
Quick Select Low Back/Hip Program Duration = 0-400 µs
Rate = 2-150 pps in 5 pps intervals
Cycle Time = 1-20s in 1s intervals
Span = 20%-95% in 5% intervals
4 Simple Modulated Pulse (SMP) Intensity = 0-60 in 0.5 intervals
Quick Select Hand/Wrist Program Duration = 0-400 µs
Rate = 20-150 pps in 5 pps intervals
Cycle Time = 1-20s in 1s intervals
Span = 20%-95% in 5% intervals
5 Modulated Amplitude (MA) Intensity = 0-60 in 0.5 intervals
Quick Select Back Program Duration = 0-400 µs
Rate = 2-150 pps in 5 pps intervals
Cycle Time = 1-20s in
1s intervals
Span = 20%-95% in 5% intervals
6 Continuous (C) Intensity (Ch1 and Ch2) = 0-60 in 0.5 intervals
Duration = 0-400 µs
Rate = 2-150 pps in 5 pps intervals
7 Burst Intensity (Ch1 and Ch2) = 0-60 in 0.5 intervals
Duration = 0-400 µs
Rate = 2-150 pps in 5 pps intervals
Cycle Time = 5-20s in 1s intervals
8 Simple Modulated Pulse (SMP) Intensity = 0-60 in 0.5 intervals
Duration = 0-400 µs
Rate = 20-150 pps in 5 pps intervals
Cycle Time = 1-20s in 1s intervals
Span = 20%-95% in 5% intervals
9 Modulation Intensity (Ch1 and Ch2) = 0-60 in 0.5 intervals
Duration = 0-400 µs
Cycle Time = 1-20s in 1s intervals
