EmpirBus NXT DCM User Manual

EmpirBus NXT DCM User manual Ver 1.53 10/15
8. Product!specifications!
See table 4.1 for model specification and hardware support
Output
Fuse setting
Output minus (-)
Output minus (-)
1, 5, 8, 10, 15, 18 A (15 and 18A not available on all models)
2 channels 0,1A minus
4 channels 0,5A minus, 3A max 20 sec (not available on all
models)
Digital input
12V power peak/average:
24V power peak/average:
Over current protection limit for LED
170mA / 1mA (closed), <0,1mA (open)
340mA / 2mA (closed), <0,1mA (open)
20mA
Analog input
Volt
Current
Resistance
0–32V +/-1%
4–20mA +/-1% (not available on all models)
0–1500 ohm +/-5%
Communication
CAN-bus
Wireless receiver
NMEA 2000
EnOcean
Power supply
Maximum current
Supply voltage
100A
9-32VDC
Connectors
NMEA 2000
Channels
Power supply
Antenna
Micro 5pin M12 Male
Molex MX150L 16 circuits
M6 bolt
SMA female
Environment
Ambient temperature
Enclosure!
-20 to +55 degrees Celsius
Ingress Protection IP65, Polycarbonate
1
Physical data
Size
Weight!
229 x 104 x 41 mm
0,4 kg!
1
Exposure to solvents and/or water above 60°C may cause cracking on polycarbonate.

EmpirBus NXT DCM Specifications

General

Brand	EmpirBus
Model	NXT DCM
Category	Switch
Language	English
