Empire AXE - Diagrams and Parts List; Marker Parts List (Ref # 1-24); Marker Parts List (Ref # 25-53)

17. Diagrams and Parts List
REF # DESCRIPTION SKU #
1 Set Screw (6-32 x .250) 17523
2 Main Board 17524
3 Battery Harness 17525
4 Board Screw 17526
5 Solenoid 17528
6 Air Transfer Plate Screw 17529
7 Air Transfer Gasket 17530
8 Check Valve 17531
9 Bolt 17532
10 Bolt Rubber Tip 17533
11 Bolt Oring 17534
12 Main Spring 17535
13 Bolt Guide Small (Front) Oring 17537
14 Bolt Guide Cap Oring 17538
15 Poppet with Spring 17539
16 Poppet Oring 17540
17 Feedneck Collar 17545
18 Feedneck Screw 17549
19 Air Transfer Tube Male Assembly 72397
20 Air Transfer Tube Male Top Oring 17552
21 Air Transfer Tube Male Bottom Oring 17553
22 Air Transfer Tube Female 17554
23 Air Transfer Tube Female Oring 17555
24 Regulator Mount 17556
25 Set Screw (10-24 x .250) 17557
26 Regulator Cap Set Screw 17599
27 Trigger Set Screw W/ Magnetic Top (chrome top) 17564
28 Primary Body Retention Screw 17565
29 Screw (BH 6-32 x .250) 17567
30 Regulator Adjustment Screw 17590
31 Poppet Spring 17623
32 Poppet Seal 17629
33 Body - Dust Black 72300
34 Barrel - Dust Black 72304
35 Grip Frame - Dust Black 72308
36 Foregrip Body - Dust Black 72312
37 Foregrip Door - Dust Black 72316
38 Air Transfer Plate - Dust Black 72319
39 Feedneck- Dust Black 72323
40 Feedneck Clamp - Dust Black 72327
41 Sensor Board 72331
42 Bolt Guide - Black Dust 72332
43 Bolt Guide Cap 72336
44 Bolt Guide Large O-ring 72340
45 Bolt Guide Lock Kit (3pc- spring, detent, button) 72341
46 Bolt Guide Release Housing 72345
47 Regulator - Dust Black (Complete) 72350
48 Black 300psi Empire gauge 72375
49 Trigger - Dust Black 72377
50 Trigger Bearing 72381
51 Trigger Pin (.155'") 72394
52 Black/White Grips 72382
53 Detent Assembly- (3pc) Dust Black 72386
