External Cleaning
Use a clean cloth, dampened with water to clean the outside of the Empire AXE. Do
not use any chemicals, as you may damage the protective finish.
Warning: Do not rinse the Empire AXE under water, as you may damage the marker’s
electronics.
Internal Cleaning and Greasing
The Empire AXE is designed for easy access to the bolt guide assembly without re-
moving any hardware. On the back of the Empire AXE is a push button to allow such
access for cleaning and maintenance. Refer to Section 15 for instructions on bolt
guide removal.
14. Storage and Transportation
Caution: Never carry your Empire AXE uncased when not on a playing field. The non-
playing public and law enforcement personnel may not be able to distinguish between
a paintball marker and firearm. For your own safety and to protect the image of the
sport, always carry your Empire AXE in a suitable marker case or in the box in which
it was shipped.
• Your Empire AXE must be clear of all paint and propellant when not being used
during transportation.
• Make sure the Empire AXE marker is off. Push the power button and hold for
2 seconds until the LED light changes from red to green.
• Put the barrel-blocking device in its place.
• Make sure the marker is clean.
• Store your Empire AXE in a clean, cool, dry place.
• Keep your Empire AXE away from unauthorized and unsafe users.
• It may be a good idea to remove the battery when storing your Empire AXE
to prevent unauthorized use.
• Protect your Empire AXE from excessive heat during transportation.
Observe and obey all local, state, and federal laws concerning the transportation of
paintball markers. For information concerning any of the laws in your area, contact
your nearby law enforcement agency.
If you must ship your Empire AXE for any reason, the box in which you purchased the
marker should be used to protect your marker against rough handling during transport.
Never ship charged CO2 or pressurized gas cylinders!
15. Assembly/Disassembly
CAUTION: Before attempting to perform any marker disassembly, make sure that all
paintballs and air sources have been removed from the marker and that the regulator
gauge reads 0 psi. Install a barrel-blocking device. Push the power button and hold
for over 2 seconds until the LED light changes from red to green. Keep the Empire
AXE power off.
Disassembly Tips
• Make sure you have a clean area to work on your marker, so you don’t lose or
misplace parts.
• Make sure the main spring is installed correctly on the bolt, as it needs to be
installed in the right direction.
• After reassembling the Empire AXE recheck your trigger activation settings.
• Visit PaintballSolutions.com for additional information.
Barrel
It is recommended that the barrel be removed before any maintenance or disassembly
is performed. Simply turn the barrel counter-clockwise to remove. Use warm water
and a barrel cleaning device to keep the barrel in top condition.
Bolt Guide Assembly
Removal of Bolt and Bolt Guide Assembly
Before you remove the bolt guide assembly, make sure you remove your air cylinder
and that the pressure gauge reads 0 psi.
• Push and hold in the bolt guide release button at the rear of the marker while the
rear of the marker is facing a safe direction.
• While holding the button in, turn the bolt guide clockwise until it stops.
• The bolt guide assembly should spring back and stop; if it does not, pull it back
until it stops.
