User’s Manual for Advanced Axial Flux Synchronous Motors and Generators
www.emrax.com Version 4.5 / January 2017 22
and 800 Arms peak motor current. Another possibility to get a high enough motor current is to connect 1 motor with 2 controllers by using 2 set of phase
connectors (2x UWV) on the motor.
2. Intended usage of the EMRAX motor/generator
Before selling the EMRAX motor, every EMRAX is tested at standard ambient and motor cooling conditions (described in
Technical Data Tables) in our Company, operating as a generator and as a motor with the Unitek GmbH BAMOCAR D3 controller.
The drive is built according to the state of the art and approved safety-related rules. However, dangerous situations for the user
or other parties as well as damages to the device or other material assets can arise.
Only use the system in technical soundness, safety-conscious, according to the intended usage and be aware of dangers!
Especially faults that can affect safety should be cleared immediately!
Do not to use the motor in direct salt environment.
Avoid full throttle idle running at higher voltages. Speed (motor rotation) must be limited by the controller SW according to the
Technical Data Table for each EMRAX type.
The EMRAX motor must be used in accordance with the ambient and motor cooling conditions, which are described in the
Technical Data Table for each EMRAX motor type, otherwise the warranty does not apply.
3. Motor types and additional motor parts
The EMRAX motor family consists of 5 different motor sizes: 188 mm, 208 mm, 228 mm, 268 mm and 348 mm diameter. Each
motor size can be air, combined or liquid cooled and each of them can also be made for high, medium or low voltage.
