EMRAX 348 - Order Codes, Tariff (HTS) Codes, Weights of EMRAX Motors and Additional Motor Parts

User’s Manual for Advanced Axial Flux Synchronous Motors and Generators
www.emrax.com Version 4.5 / January 2017 25
*For more information about suitable sensors, for each controller, contact the controller producer.
4. Order codes, tariff (HTS) codes, weights of EMRAX motors and additional motor parts
Sample of order code: EMRAX_228_HV_LC(IP65)_ R _LTN_180
EMRAX speed and position sensors
Resolver
- Mounted on back or front motor side. More
information about mounting is in Item 7, 8, 9, 10.
- Two resolvers can be mounted serially - Tandem
Resolver, which are used when two controllers are
used. For EMRAX TWIN application or 2x UVW
phase connectors on one motor.
LTN RE-15-1-A15
(e.g. for Unitek controllers*)
TLTN RE-15-1-A15
(tandem resolver; e.g. for two
Unitek controllers*)
Encoder
- Mounted on back or front motor side. More
information about mounting is in Item 7, 8, 9, 10.
RLS RM44SC (SSI)
(e.g. for Emsiso controllers*)
RLS RM44AC (sin-cos)
(e.g. for Sevcon controllers*)
Hall Sensors (HS)
- Mounted in the motor during
assembly.
- For various controllers*.
EMRAX bracket
X shape for one EMRAX motor
X shape for EMRAX TWIN
Item code:
Explanation:
Weight (kg)
Tariff (HTS)
codes and
description
EMRAX
Motor name
7 / 9 / 12 / 20
/ 40
8501.52.9;
electric motor
188 / 208 / 228 /
268 / 348
Motor diameter in mm
LV / MV / HV
Voltage type (Low Voltage / Medium Voltage / High Voltage)
LC(IP65) / CC(IP21) /
AC(IP21)
Liquid Cooled (IP65) / Combined Cooled (IP21) / Air Cooled (IP21)
R
Bearings for radial forces.
P
Front bearing is for radial forces. Back bearing is for axial-radial forces, focusing on very high axial load.
Bearing combination is for pull mode. For e.g. air propeller.
PP
Front bearing is for radial forces. Back bearing is for axial-radial forces. Bearing combination is for pull-
push mode.
2xUVW
2 sequences of phase connectors (6 motor phases). When using one motor with two controllers to get a
high enough current.
VHML
Bearings and motor shaft made for Very High Mechanical Loads (VHML). Stronger bearings and stronger
shaft. Possible only for EMRAX 268.
LTN(back)
Resolver LTN RE-15-1-A15 (e.g. for Unitek Bamocar D3 controller) with bracket mounted on back side of the
motor.
0,2
9031.80.98;
speed and
position
sensor
LTN(front)
Resolver LTN RE-15-1-A15 (e.g. for Unitek Bamocar D3 controller) mounted on the front motor side by a
special bracket. This bracket has to be connected with X shape bracket, which is mounted on the back
motor side. Special bracket, X shape bracket and connecting parts are included.
0,3
