EMS FIRECELL - System Design and Handling Precautions; System Design Principles; ESD Precautions

©2018 EMS Ltd. All rights reserved. Page 4 of 24 TSD115 Iss2 17/09/2018 AJM
Wireless RIM familiarisation
www.emsgroup.co.uk
Wireless Detector Base
PRESS HERE TO
LOG ON
Part No: FCZ-170-111
Wireless Module
Log on button
Power jumper
Ident number
device
unpowered
(pins unlinked)
device
powered
(both pins linked)
RevX DD/MM/YY
1d872
Battery compartment Remote Indicator
Fire LED
Conrmation
LED
PRESS HERE TO
LOG ON
