Adding a Wireless RIM to a FireCell Radio Hub (manually)
Take the device to the Radio Hub and follow the steps below:
With the radio hub in its normal state the screen will display:
DEV15 AL00 FT00
Press the rotary control and the screen will display:
Device Status
Turn the rotary control until the screen displays:
Add New Device
Press the rotary control and the screen will display:
RCC01=06 Max 31
Turn the rotary control, until the screen displays the required
RCC to programmed the device to:
RCC02=03 Max 31
Press the rotary control and the screen will display:
Add By Log On
Turn the rotary control until the screen displays the required
addressis shown and press the rotary control to select. The
Loop 1 Addr 016
Press Dev Log On
Press the rotary control and the screen will display:
If the ident shown does not match the ident of the new device to be added, press the rotary
control (with the above Add Dev xxxxx N? display shown). This will return the display to the
previous menu.
Add Dev xxxxx N?
Press the device log on button for 2 seconds. The device’s
conrmation LED will illuminate and the she screen will display:
New Addr L2 A007
Press the rotary control and the screen will now conrm the new
devices loop and address number:
Add Dev xxxxx Y?
Conrm the ident number displayed is the same as located on the
device. If correct, turn the rotary control until the screen displays:
Press the BACK button until the screen displays:
Unassigned Dev
Press the rotary control and the screen will display:
Device Status
Turn the rotary control until the screen displays the required
Loop to be programmed and press the rotary control to select.
Loop 2 Addr 007
To Next Page
